WKASY-1000A computerized high speed rotogravure printing presses

WKASY-1000A series computer high speed gravure printing machine, which adopts advanced seven-motor tension control system, tension pick up by dance rollers; centrelization controlled by PLC program; with non-stop, auto splicing and cutting device; auto color register system.

WKASY-1000A computerized high speed rotogravure printing presses

Introduction:

WKASY-1000A series computer high speed gravure printing machine, which adopts advanced seven-motor tension control system, tension pick up by dance rollers; centrelization controlled by PLC program; with non-stop, auto splicing and cutting device; auto color register system.

Technical specification:

1.Printing color: 8 colors 10 units

2.Max. width of material: 1030mm

3.Max. Printing width: 1000mm

4.Max. Mechanical speed: 160m/min.

5.Max. Printing speed: 150m/min.

6.Max diameter of unwind and rewind: 800mm

7.Diameter of cylinder: 100mm-320mm.

8.Color register precision: ≤±0.10mm

9.Machine power:  165kw

10.Overall dimension: 17500×3000×2620mm (L*W*H).

11.Net weight: 24T

12.Printing material:Non-woven,Cellophane,PET,PE,OPP,BOPP,CPP,PVC,NY,PAPER,and other laminated film

Please write more details of your specific requirement, so our sales team can provide you right machine you need.
