KSZ-90 Horizontal Automatic cartoning Machine

Automatic cartoning machine is a packaging equipment, which fill products into carton automatically.

KSZ-90 Horizontal Automatic cartoning Machine

Introduction:

Automatic cartoning machine is a packaging equipment, which fill products into carton automatically. The machine is combined the function, feeding boxes, forming box, folding leaflet, encasing products and leaflets into carton, printing batch number, sealing boxes, rejecting and transferring final product out. The machine can reduce the working intensity and save labor force cost; and production effectively. The machine is widely applied to carton case packaging in Pharmaceutical, Food, Cosmetic, Stationery, hardware, and ETC.

Product Feature:

1.International famous brand of electrical component such as PLC touch screen, frequency inverters, etc.

2.Adopt human-machine operation system.

3.Automatically stop when machine is overload.

4.Automatically reject lacking of package product and leaflet.

5.Automatically display trouble, Alarm and count finished products.

6.Stable performance, operation is easy.

Technical Specification:

Item

Parameters

Encasing speed

30-90 boxes/min

Box

Quality requirement

250-350g/㎡ (Base on carton size)

Dimension range

(L×W×H)

(65-125)mm×(35-90)mm×(12-60)mm

Leaflet

Quality requirement

60-70g/㎡

Unfolded leaflet specification

(L×W)

(80-250)㎜×(90-170)㎜

Fold range

(L×W)

(1-4)Fold

Compressed air

Working pressure

≥0.6mpa

Air consumption

120-160L/min

Power supply

220V 50HZ

Main motor power

0.75kw

Machine dimension(L×W×H)

1265㎜×1135㎜×1640㎜

Machine weight

about 1000kg
