FQ Series Computer Control Heat-sealing and Cold Cutting Bag Making Machine

1. The whole machine adopts micro-computer control and material-pulling by stepping motor(servo motor control system can also be selected and equipped)
2. Arbitrary fixed-length, accurate and stable step photoelectric tracking, stopping automatically when the label is lost, photoelectric control feeding.

This plastic bag making machine is for produce the shopping bag, vest bag etc.

Features:

1.  The whole machine adopts micro-computer control and material-pulling by stepping motor(servo motor control system can also be selected and equipped)

2.  Arbitrary fixed-length, accurate and stable step photoelectric tracking, stopping automatically when the label is lost, photoelectric control feeding.

3.  Automatic counting and settable counting alarm.

4.  Automatic constant temperature makes the sealing of bag opening firm and smooth.

Technical specifications:

Model

FQ500

FQ600

FQ700

FQ800

Max. bag-making width

500mm

600mm

700mm

800mm

Max. cutting length

999mm

999mm

999mm

999mm

Production capacity

30-140pcs/min

30-140pcs/min

30-140pcs/min

30-140pcs/min

Total Power

3.3kw

3.5kw

3.7kw

4.3kw

Weight of machine

800kg

900kg

1000kg

1100kg

Overall dimensions

330×94×160cm

330×104×160cm

330×114×160cm

330×142×160cm

Please write more details of your specific requirement, so our sales team can provide you right machine you need.
