KGUV-1000/1200 Automatic Whole UV Coating Machine

Features:
KGUV-1000/1200 automatic whole UV coating machine is designed based on the semi-auto UV coating machine.

KGUV-1000/1200 Automatic Whole UV Coating Machine

Features:

KGUV-1000/1200 automatic whole UV coating machine is designed based on the semi-auto UV coating machine. With frequency conversation control, oil quantities which are decided according to the different thickness of paper can be controlled by different linear velocity. With easy operation, fundamental improvement in the printing paper surface and smoothness of coating products without orange peel veins, the machine optimizes polishing products.

Technical specifications:

Model

KGUV-1000

KGUV-1200

Max. paper size

780×950mm

780×1150mm

Min. paper size

340×240mm

340×240mm

Max. coating width

950mm

1150mm

Paper thickness

80-600g/㎡(with air knife)

200-600g/㎡

80-600g/㎡(with air knife)

200-600g/㎡

Max. feeding speed

8000pcs/hour(thick paper)

4000pcs/hour(thin paper)

8000pcs/hour(thick paper)

4000pcs/hour(thin paper)

Total weight

6500KG

7000KG

Total power

65KW

65KW

Overall dimensions

16000×1880×1710mm

16000×2080×1710mm
